PANDUIT
TWO-HOLE STANDARD BARREL LUG WITH WINDOW, 1/0 AWG, 1/2 IN STUD, 1.75 IN HOLE SPACING, TIN-PLATED COPPER
Product Code: LCD1/0-12-X
AED145
AED225
Save 36%
/ Unit
In Stock — Ready for immediate dispatch from Dubai
COPPER COMPRESSION LUG, 2-HOLE, STANDARD BARREL, 1/0 AWG, 1/2" STUD, 1.75" HOLE SPACING, TIN-PLATED COPPER, INSPECTION WINDOW, PINK DIE CODE P42, PANDUIT PAN-LUG™
Two-Hole Standard Barrel Copper Compression Lug with Inspection Window, for 1/0 AWG stranded copper conductor, 1/2 inch stud holes with 1.75 inch (44.5 mm) hole spacing. Manufactured from high-conductivity tin-plated copper for excellent electrical performance and corrosion resistance. Color-coded Pink barrel with Die Index P42 for reliable crimping in industrial, utility, and power distribution applications.
| Series | Pan-Lug™ LCD |
| Connector Type | Two-Hole Compression Lug |
| Conductor Size | 1/0 AWG Copper (Stranded) |
| Material | High-Conductivity Copper |
| Finish | Electro Tin Plated |
| Barrel Type | Standard Barrel |
| Stud Size | 1/2 in (12.7 mm) |
| Hole Spacing | 1.75 in (44.5 mm) |
| Overall Length | 4.25 in (108 mm) |
| Color Code | Pink |
-
DownloadDatasheetPDF · 86.7 KB
